32KW full DC Inverter EVI air source heat pump heating

In order to solve the traditional solar/gas/electric hot water hot water supply instability, as well as gas leakage poisoning, electrocution and other safety hazards, as well as low energy utilization and to meet the family's multiple needs, ultra-low temperature inverter air-source heat pump technology, for us to create whole-house floor heating, air conditioning, hot water solutions. Using air as the heat source, it can efficiently produce heat at the extremely low temperature of -35°C. It adopts the method of water and electricity separation, without the risk of combustion and explosion, and the system runs more safely and stably. It can accurately control the water temperature, with a temperature difference fluctuation of less than 0.5°C, and realize 24-hour constant temperature circulating hot water.

    Heat pump main proudcts

    1.cooling/heating heat pump
    2.heat pump water heater
    3.cooling/heating//hot water heat pump
    4.industrial and agricultural drying
    5.photovoltaic energy storage
    6.swimming pool heat pump
    7.Industrial cooling and heating
    8.Agricultural greenhouse environmental control
    9.Heat Pump Accessories
    215641427

    Product Details

    R290 refrigerant
    Zhenxin air source heat pump uses new environmentally friendly refrigerant R290, which does not contain chlorofluorocarbons, will not have a destructive impact on the ozone layer, and has a small global warming potential. It has good thermal conductivity and high refrigeration efficiency, which can effectively reduce energy consumption.
    detail (4)zl0detail (5)gvudetail (1)be1
    Full DC Inverter Technology
    the three core motors of the heat pump (inverter compressor motor, indoor fan motor, outdoor fan motor) are all powerful DC motors, and with the innate advantages of DC motors, as well as matching the advanced control system, the full DC inverter heat pump, whether it's the level of energy saving or the performance of the whole machine has reached an Higher level of technology
    EVI:Enhanced Vapor Injection Technology
    The unit refrigeration capacity of jet enthalpy increase is higher than the ordinary refrigeration cycle, the low-temperature gaseous refrigerant directly into the intermediate chamber, lowering the internal temperature of the compressor, thus reducing the exhaust temperature of the compressor outlet, and improving the stability of the operation of the refrigeration system.
    detail (3)t56detail (2)ybqdetail (6)fe9
    Stable Running at -35℃~48℃ Ambient Temperature
    Thanks to the unique Inverter EVI technology, can operate efficiently at -35°C, maintain high COP and reliable stability. Intelligent control, any weather available, automatic load adjust under different climate and environment to satisfy the demands of summer cooling, winter heating and hot water throughout the year.
    Principle-1qot

    Product Parameters

    Product Model DKFXRS-32II-HBC
    Rated heating capacity (A7 W41) 32.3kw
    Rated Input Power 9.72kw
    Performance parameters (COP) 3.32
    Nominal heating capacity (A-12W41) 24.1kw
    Nominal Input Power 9.96kw
    Coefficient of performance COP/IPLV 2.42/2.83
    Rated cooling capacity (A35 W7) 24kw
    Rated power 8.82kw
    Performance parameter COP 2.72
    Rated voltage/frequency 3N~380V   50Hz
    Refrigerant R290/R32/R410A
    Maximum operating power 12.6kw
    Maximum operating current 25A
    Circulating water flow 4.2m³/h
    Circulating water pipe diameter DN40
    Unit external dimensions (mm) 1290*450*1570
    Noise 68db(A)
    Net weight 205kg
